Page 18 - Shimadzu ICPE-9800 Series

Peripheral Equipment

For automatic analysis of 60 samples For automatic analysis of 240 samples For automatic analysis of 120 samples
AS-10 Autosampler ASX-560 Autosampler ASX-280 Autosampler
(P/N 211-93680-58) (P/N 211-94230-01) (P/N 211-94412)
Multiple samples can be analyzed Vials: Vials:
successively. The turntable results 10 50-mL vials (standard 10 50-mL vials (standard samples)
in a short path length for sample samples) or 240 14-mL vials or 120 14-mL vials
injection, which can reduce the 160 20-mL vials (rack sold separately) 80 20-mL vials (rack sold separately)
rinse time. 84 50-mL vials (rack sold separately) 42 50-mL vials (rack sold separately)
Vials: 60 15-mL vials Size: W580 × D550 × H620 mm Size: W355 × D550 × H620 mm
8 50-mL vials (include sample probe) (include sample probe)
Size: W290 × D508 × H300 mm (excluding arm) W90 × D180 × H60 mm W90 × D180 × H60 mm
Power supply: Single-phase 100–240 V, 50/60 Hz, 50 VA (rough dimensions of power supply unit) (rough dimensions of power supply unit)
Power supply: 100-240 V AC, 47-63 Hz, 1.9 A Power supply: 100-240 V AC, 47-63 Hz, 1.9A
Note: Requires a Power Cord.
Note: An additional rinsing port is optional (There is no automatic Weight: 11.7 kg (main unit) Weight: 8.1 kg (main unit)
solvent supply). Note: Requires an ASX Connection Kit ICPE-9800 Note: Requires an ASX Connection Kit ICPE-9800
Rinsing Port Expansion Kit for AS-10 (P/N 211-94072-41) (P/N 211-94610-41). (P/N 211-94610-41).
For high-sensitivity analysis of As, Se, and Sb Cooling Water Circulator
Hydride Generator HVG-1 (P/N 211-92962-41)
(P/N 206-17143-41 to 58)
Used to cool the main unit, the cooling jacket, and the
Note: HVG-ICP Connection Kit for ICPE-9800 (P/N 211-92481-58) ultrasonic nebulizer.
and pump are required. Size: W377 × D500 × H615 mm
Power supply: AC 200 V–230 V, 50/60 Hz, 2 kVA
Weight: 43 kg
Quality Control Software Note: A Chiller Connection Kit (P/N 211-93827-41), or a Chiller
ICPEsolution QAQC Connection Kit, UAG (P/N 211-92894-42) is necessary.
(P/N 211-49146-91) Note: Two hoses (10 m) are included in the connection kit. One is for
the supply of cooling water, the other for draining water.
This software is based on QAQC items obtained USEPA CLP SOW ILM05.x.
Tap Water Connection Kit
For constructing data management system compatible with FDA 21 CFR Part 11 (P/N 211-90558-41)
Multi-Data Register Connection Kit for ICPE
(P/N 211-95546-92 (English) / -93 (Chinese)) This is required if using tap water to cool the main ICPE-9800 unit.
Note: A Coupler Set for Tap Water Connection (P/N 035-60942-15) is required.
Supports data storage and management, user management and audit trails by connecting
with LabSolutions DB/CS. A license for the LabSolutions Multi-Data Register function is
required separately. For reducing the suction volume of small amounts of samples by half
Nebulizer, 07UES
(P/N 046-00092-21)
For high-sensitivity analysis of Na or K in organic solvent samples
A nebulizer with high-efficiency • Suction Tube, NFTS-075
Argon and Oxygen Gas Mixture Supply Unit (special order) nebulization. (P/N 046-00092-18)
(Sample suction rate of approx. • Connector, QSM
Normally, the ICPE-9800 does not require oxygen gas to be added to the plasma when organic 0.6 mL/min) (P/N 046-00092-09)
solvent samples are measured. However, when trace amounts (ppb levels) of elements such as Na • Tube adaptor, 0735
and K in organic solvent are measured, carbon can cause background problems. A four-layered (P/N 046-00092-10)
torch is useful for reducing such problems by introducing oxygen safely into the plasma.
• Clamp, SNP-1
(P/N 037-61113-01)
These are included.
Peristaltic Pump For adding internal standards automatically to ensure
(P/N 211-92430-41) accurate analysis with ease
Automatic Internal Standard Addition Kit
Installed internally, with up to four channels (P/N 211-92883-41)
Size: W121 × D174 × H131 mm
(excluding protrusions) This kit is used for in-line mixing of a sample solution to be
This pump is also used with the automatic measured and an internal standard element solution and for
internal standard addition kit. introducing the mixture into the ICP system.
Note: Peristaltic Pump (P/N 211-92430-41) is required.

Option (Third-Party)
Hydride Generator hydride FAST/Manufactured by Elemental Scientific Inc. Ultrasonic Nebulizer U5000AT/Manufactured by CETAC Technologies Inc.
ESI: IsoMist:
ESI’s hydride ICP Generation System is used to concentrate hydride forming elements before Temperature-controlled sample introduction kit. The temperature is electronically controlled
analysis with Shimadzu’s ICPE-9800 Series. using a powerful inbuilt Peltier device. You can select any temperature between −10°C and
By increasing the concentration, sensitivity of the ICP spectrometer increases for elements like +60°C in 1°C increments to provide the optimum conditions for any application. The rapid
Hg, Se, As, Sn, Te and Bi. response of the Peltier device allows a spray chamber temperature of −5°C.
CETAC: Twister Spray chamber:
CETAC U-5000AT + Ultrasonic Nebulizer for ICPE-9800 Series. Increase sensitivity about a factor Used for non-volatile organics. The Twister cyclonic spray chamber features a central transfer
of 10×, but varies element to element. General use is for aqueous solutions. tube which acts as a secondary particle separator helping separate larger aerosol particles from
the sample. This reduces solvent load in the plasma without compromising detection limits.

18
