Page 6 - Kubota - 3740
P. 6

The temperature of sample is kept 4℃ at maximum speed of rotation for all rotors (when the ambient temperature is 25℃).
            Fixed angle rotor (5mL)


                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity
                                                             diam. x length  Maximum Speed  Maximum RCF  Code No.
                                                                              rpm           xg
                                  AF-512      12 x 5mL         15 x 59  *1   15,000       20,880        ―


                     Autoclavable*
          AF-512
          12 x 5mL
          Highly recommended when
          the capacity of 2mL tube is
          not enough.


            Fixed angle rotor (middle size)


                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                 AF-1408A     8 x 14mL       17 x 75〜100  *2  12,000      14,330        ―


                     Autoclavable*
          AF-1408A
          8 x 14mL
          Falcon round bottom tubes
          (dual-position snap cap) are
          available.

                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity
                                                             diam. x length  Maximum Speed  Maximum RCF  Code No.
                                                                              rpm           xg
                                              4 x 50mL    28.5〜29.0 x 102〜115 *3  15,000  21,880        ―
                                AF-5004RA     4 x 12mL    15.8〜16.4 x 103〜110 *4  15,000  20,630      055-7410
                                              4 x 10mL     16.0〜16.3 x 79〜92  *5  15,000  20,630      055-4280  *6

                     Autoclavable*
          AF-5004RA
          4 x 50mL
          10mL anti-biohazard sealing
          adaptors (code no. 055-
          4280) can be used.


                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                              6 x 38mL    25.0〜25.6 x 87〜103 *7  15,000   21,880        ―
                                 AF-3806A     6 x 30mL    25.4〜25.7 x 87〜102.6 *8  15,000  21,880       ―
                                              6 x 10mL     16.0〜16.6 x 72〜82  *9  15,000  19,370      055-4570
                     Autoclavable*
          AF-3806A
          6 x 38mL
                                  Rotor has prescribed operating life cycle, after that the rotor must be replaced.
                                  For more details, please contact us.
                               * The number of times allowed for autoclaving is limited. For more details, please contact us.
                               *1  Biobic 5mL sampling tubes and Watson 5mL mega tubes can be used.
                               *2  Falcon round bottom tubes (catalogue no.352006, 352018, 352059) are available.
                               *3  Nalgene tubes (catalogue no.3110-0500/PPCO, 3110-9500/PPCO, 3117-9500/PC, 3114-0050/FEP, 3115-0050/PSF, 3118-0050/PC,
                                  3119-0050/PPCO, 3137-0050/PSF, 3138-0050/PC, 3139-0050/PPCO) and stainless steal tubes (code no.052-6910) can be used.
                               *4  Nalgene tubes (catalogue no.3110-0120/PPCO, 3117-0120/PC) are available.
                               *5  Nalgene tubes (catalogue no.3114-0010/FEP, 3115-0010/PSF, 3118-0010/PC, 3119-0010/PPCO) are available.
                               *6  055-4280 sealing adaptors can be used for anti-biohazard.
                               *7  Nalgene tubes (catalogue no.3110-0380/PPCO, 3117-0380/PC) are available.
                               *8  Nalgene tubes (catalogue no.3114-0030/FEP, 3115-0030/PSF, 3118-0030/PC, 3119-0030/PPCO, 3138-0030/PC, 3139-0030/
                                  PPCO) can be used.
                               *9  Nalgene tubes (catalogue no.3118-0010/PC, 3114-0010/FEP, 3115-0010/PSF, 3119-0010/PPCO) can be used.
