Page 235 - Shimadu Consumables Catalog

Single Filters COMBI Filters

Catalog No. 226-50754-00 Catalog No. 226-50750-00 COMBI (HYDROCARBON/MOISTURE)
MOISTURE FILTER FILTER
Specifications Specifications
Moisture in carrier gas lines will The Fuel Gas Filter is perfect for purifying
Outlet Gas Quality (%) > 99.9999 Outlet Gas Quality (%) > 99.9999
prematurely degrade oxygen and flame ionization detector (FID) fuel
Maximum Pressure 11 bar (160 psi) hydrocarbon traps and increase detector Maximum Pressure 11 bar (160 psi) gases, removing both moisture and
Maximum Flow 7 L/min. noise. As a precaution, we higly Maximum Flow 7 L/min. hydrocarbons. Using the Fuel Gas Filter
Usable For Inert carrier gas, He, H2, N2, AR, recommend installing a moisture trap Usable For Inert carrier gas, He, H2, N2, AR, for FID Hydrogen and air will produce
Air before the hydrocarbon and oxygen Air a stable baseline, improving overall
traps on all carrier gas lines. reproducability and sensitivity.
Dimensions 24 cm x Ø 4.4 cm Dimensions 24 cm x Ø 4.4 cm
Capacity Capacity
Weight 0.26 Kg Weight 0.26 Kg
H O 7.2 g H O 3.5 g
Estimated Lifetime > 2 years 2 Estimated Lifetime > 2 years 2
HC 6 g (as n-butane)

Catalog No. 226-50755-00 OXYGEN FILTER Catalog No. 226-50758-00
Specifications Oxygen is a column killer. It is present Specifications COMBI (OXYGEN/MOISTURE) FILTER
even in UHP gases, as minutes leaks at
Outlet Gas Quality (%) > 99.9999 Outlet Gas Quality (%) > 99.9999 This Combi trap is ideal for purifying
fittings allow oxygen to influx against
Maximum Pressure 11 bar (160 psi) the concentration gradient. Because Maximum Pressure 11 bar (160 psi) carrier gas. It contains oxygen and
Maximum Flow 7 L/min. oxygen can enter a gas line at any Maximum Flow 7 L/min. moisture scrubbers in one easy to change
economical cartridge
Usable For Inert carrier gas, He, H2, N2, AR fitting or during gas bottle exchange, Usable For Inert carrier gas, He, H2, N2, AR
the oxygen trap should be the last Capacity
Dimensions 24 cm x Ø 4.4 cm connection before the gas line enters the Dimensions 24 cm x Ø 4.4 cm
Weight 0.26 Kg chromatograph. Weight 0.26 Kg H O 3.5 g
2
Estimated Lifetime > 2 years Capacity Estimated Lifetime > 2 years HC 75 mL
O2 150 mL

Catalog No. 226-50756-00 HYDROCARBON FILTER Catalog No. 226-50759-00
Specifications Use a hydrocarbon trap if your gas Specifications
has a potential source of hydrocarbon COMBI (CARBON DIOXIDE/
Outlet Gas Quality (%) > 99.9999 Outlet Gas Quality (%) > 99.9999
contaminants or if you suspect you MOISTURE) FILTER
Maximum Pressure 11 bar (160 psi) are observing carrier gas ghost peaks. Maximum Pressure 11 bar (160 psi) Removes carbon dioxide and moisture
Maximum Flow 7 L/min. Install the hydrocarbon trap after the Maximum Flow 7 L/min. from gas streams.
Usable For Inert carrier gas, He, H2, N2, AR, moisture trap, to prevent moisture from Usable For Inert carrier gas, He, H2, N2, AR, Capacity
Air degrading the hydrocarbon-trapping Air
ability of the activated carbon in the H O 3.5 g
Dimensions 24 cm x Ø 4.4 cm Dimensions 24 cm x Ø 4.4 cm 2
hydrocarbon trap. HC 6 g
Weight 0.26 Kg Weight 0.26 Kg
Capacity
Estimated Lifetime > 2 years Estimated Lifetime > 2 years
HC 12 g (as n-butane)

Catalog No. 226-50757-00 Catalog No. 226-50751-00
226-50752-00 (Helium Specfic)
Specifications 226-50752-10 (Hydrogen Specific) TRIPLE (OXYGEN/MOISTURE/
Outlet Gas Quality (%) > 99.9999 CARBON DIOXIDE FILTER Specifications HYDROCARBON) FILTER
Maximum Pressure 11 bar (160 psi) Removes carbon dioxide from gas Outlet Gas Quality (%) > 99.9999 The Triple trap is ideal for purifying
Maximum Flow 7 L/min. streams. To be used in combination with Maximum Pressure 11 bar (160 psi) carrier gas. It contains oxygen, moisture
and hydrocarbon scrubbers in one easy to
Usable For Inert carrier gas, He, H2, N2, AR, a Moisture Filter change economical cartridge
Air Capacity Maximum Flow 7 L/min.
Dimensions 24 cm x Ø 4.4 cm CO2 12 g Usable For Inert carrier gas, He, H2, N2, AR Capacity
Weight 0.26 Kg Dimensions 24 cm x Ø 4.4 cm H O 1.8 g
2
Estimated Lifetime > 2 years Weight 0.26kg O2 75 mL
Estimated Lifetime > 2 years HC 4 g (as n-butane)

Pg D-11
