Integrating Sphere Units

Integrating Sphere Attachment (ISR-2600/ISR-2600Plus) Multipurpose Large-Sample Compartment (MPC-2600A)
(P/N 206-28400-58/206-28410-58) (P/N 207-23520-41)

These units can be used for relative diffuse or specular režectance measurements. The angle The MPC-2600A enables both režectance and transmittance measurement of samples having
of incidence to the sample can be set by setting it to zero or eight degrees in combination a wide variety of shapes. The measurement wavelength range is 220 to 1400 nm. It is
with functionality for switching between sample and reference sides of the spectrophotom- compatible with transmitted samples that are ø305 mm/50 mm thick or less or ø204 mm/300
eter. The measurement wavelength range is 220 to 850 nm for the ISR-2600 or 220 to 1400 mm thick or less, režectance samples that are ø305 mm/50 mm thick or less.
nm for the ISR-2600Plus. They are compatible with režectance samples that are W95 × H135
× T20 (for 0-deg. angle of incidence) or W70 × H70 × T12 (for 8-deg. angle of incidence).
Large Polarizer Assy / Polarizer Assys Powdered Sample Holder Micro Sample Holder
(for Integrating Sphere) (P/N 206-28055-41)
(P/N 206-89065-41)

These enable control of polarization characteristics of This powdered sample holder is for installation in an This holds small samples against the integrating sphere.
incident light on samples. integrating sphere. It is compatible with sample sizes from 5 to 10 mm square
and between 0.5 and 2 mm thick.
P/N Type Wavelength range
206-15694-40 Large type 250 to 2300 nm
206-13236-41 Type I 400 to 800 nm
206-13236-42 Type II 260 to 700 nm
206-13163-40 Type III 260 to 2300 nm
Re ectance Measurement

Absolute Re ectance Attachments Variable Angle Measurement Unit Specular Re ectance Measurement
for MPC-2600A (P/N 207-23490-41) Attachment (5° Incident Angle)
(P/N 206-14046-58)

These attachments are installed in a multipurpose large- This device enables absolute režectance measurements of This device enables specular režectance measurements. The
sample compartment to enable absolute specular režectance solid samples, with the incident and re žection angles set angle of incidence to the sample is 5 degrees. It is
measurements of solid samples. The measurement to any angle. Measurement wavelength range is 250 to compatible with sample sizes from 7 mm in diameter up to
wavelength range is 300 to 800 nm and compatible sample 1400 nm. It is compatible with sample sizes from 20 to 160 × 100 mm and up to 15 mm thick.
size range is 20 to 150 mm square and up to 30 mm thick. 70 mm square and between 2 and 15 mm thick. The
A sample base plate integrating sphere set is required. incident angle can be set between 5 and 70 degrees.
P/N Incident angle
206-16817-58 5°
206-16100-58 12°
206-15001-58 30°
206-15002-58 45°
Various other accessories

Liquid Samples Solid Samples

https://www.shimadzu.com/an/ https://www.shimadzu.com/an/
molecular_spectro/uv/accessory/liquid/guide.html molecular_spectro/uv/accessory/solid/guide.html

UV-2600i/UV-2700i
UV-VIS Spectrophotometer 19
