Enhanced Support System for Data Management

LabSolutions DB/CS Realizes Complete Data Integrity*
™

Multianalyte Data Analysis with More Efficiency Using LabSolutions Insight
LabSolutions Insight quantitative analysis support software includes functionality for enhancing the throughput of
multianalyte data analysis, making it especially helpful for routine analysis. Quantitative results for a series of data sets
can be displayed at the same time for data analysis. Chromatograms for each set of sample data can be displayed
side-by-side for each compound, making it easy to confirm peak detection and quantitative results. Color-coded flagging
functionality makes it easy to quickly see peaks from any of multiple analytes that exceed criteria values. That drastically
decreases the number of peaks that need to be checked and improves the efficiency of quantitative analysis processes.

More Efficient Multianalyte Data Analysis LabSolutions DB/CS is the integration software for analytical instruments that complies with regulations regarding electron-
Users can select the optimal method for displaying data based on their workflow. For example, data analysis windows can ic records and signatures, such as "FDA 21 CFR Part 11" and "ER/ES guidelines".
be displayed for each target compound or each set of measurement data, or quantitation or area values can be displayed as Data management with LabSolutions prevents overwriting or deleting analysis data. It also offers a complete suite of
a list. If necessary, quantitative analysis can be repeated with peaks directly corrected, which provides intuitive operability. advanced security features to provide an optimal solution for data integrity.

Visualization of Quantitative and Accuracy Control Results Network System: LabSolutions CS
Quantitative and accuracy control results can be presented more clearly by using the flagging function to color-code result Data acquired from multiple systems can be reviewed or confirmed using client computers connected via a LAN or other
values that exceed specified criteria values or by only displaying flagged results. Five levels of criteria values can be indicated network. If multiple systems are used, data obtained from each system can be reviewed from any client
for quantitative results, making it easy to confirm the corresponding criteria value range for the detected compounds. computer. Even in the case of multiple analysts using the same system, the ability to separate analytical work from measure-
Flagging immediately reflects results from any corrections made to manual peak integration or calibration curves.
ment work improves work efficiency.
* 3 * 2
LabSolutions server Laboratory or office Tablet Client PC

Cautionary Warning

* 1
Acquisition
0.000001 mg/L 0.00001 mg/L cotoroller PC

EDX TOC-V AA
LC GC Agilent LC, GC Thermo LC, GC Combine with
Multi-Data Registration License
to enable integrated management
of these instruments’ data and
user information.
Network Support Laboratory
LCMS GCMS FTIR UV RF TA
GC/MS analysis LC/MS analysis
Data acquired from multiple systems PC
can be reviewed or confirmed using
client computers connected via a
LAN or other network. If multiple
A instrument B instrument
systems are used, data obtained
from each system can be reviewed Operator Operator Combine with
Multi-Data Registration License
from any client computer. Even in Balance PPSQ ™ ICPMS Particle Size AG TOC-L to enable integrated management
Analyzer
the case of multiple analysts using
the same system, the ability to Office *1 The acquisition control PC controls analytical instruments. It can also be used to send analytical instructions and perform postrun analysis, just like a client PC.
*2 If a terminal service is used, then LabSolutions software does not need to be installed on client PCs.
separate analytical work from *3 If an iPad is used, then XenApp from Citrix must be installed.
Data review
measurement work improves
efficiency.
Standalone Database System: LabSolutions DB
File Server
Client PC LabSolutions DB manages data by connecting a computer with analysis instruments, which do not have network connections. It is
Analysis administrator recommended for facilities that do not require network connections and want to be ER/ES compliant with one computer.
Data confirmation Client PC Operator Client PC Operator Client PC Operator
*LabSolutions DB/CS is optional software that provides enhanced data integrity support. Some analysis systems and functions are not supported in contrast to the standard
File management on a file server is recommended for systems with more than five users.
workstation software GCMSsolution.
