Page 15 - Automotive Solution for Automotive

Fatigue/Endurance Testing Machine for Various Materials and Compact Parts Various Test Jigs Used for Precision Universal Testing Machines
EHF-EM/EV Series Servopulser Fatigue and Endurance Gasket Compression Testing Machine for Cylinder Head 45° Peel Test Jig for Printed Circuit Boards Shearing Test Jig for Electronic Components
Testing Machine Precision Universal Testing Machines
This test jig is for peel testing of electric and This test jig is for shearing testing of electric
This standard series, typical of the lineup of Gaskets are widely used as automobile materials electronic components on printed circuit and electronic components mounted on
Shimadzu electrohydraulic servo-type fatigue because they provide air and water tightness. So boards. It also supports test methods for printed circuit boards. The position of the
testing machines, boasts an extensive track record numerous performance properties including heat, lead-free solders (JIS Z3198-6). specimen is determined by the X-Y stage.
and consistent performance. It can cover static pressure, and chemical resistance are required of
testing to fatigue tests. gaskets.
This testing machine can obtain compression,
Maximum Test Force : Dynamic ±50, ±100, ±200 kN fatigue, and sealing characteristics in low- to
Maximum Stroke : ±25 mm, ±50 mm high-temperature environments. Static and
Waveform : Sine, triangular, rectangular, dynamic tests are supported by the Precision
ramp,haversine
Control : Test force, stroke Universal Testing Machines and Fatigue and
Endurance Testing Machine, respectively. Three-/Four-Point Bending Test Jigs for Printed Circuit Boards Cyclic Bending Test Jig for Printed
Circuit Boards
Bending test jigs for printed circuit boards and
printed circuit boards mounted with This test jig is for cyclic bending tests of
components. printed circuit boards. Properties such as
resistance fluctuations due to the application
of cycle loads can be observed.

Thermal Fatigue Testing of Engine-Related Tubing Materials Internal Pressure Fatigue Testing of Pipes etc.
Strength Test Jig for Surface Mounted Components
Thermal Fatigue Testing Machine Internal Pressure Fatigue Testing Machine This jig is for body strength bending tests of
Punch Specimen
This testing machine is capable of temperature This testing machine can apply loads using a sine surface-mounted components based on JEITA
cycle testing at high control precision. The strain wave of max. 10 Hz and max. pressure of 250 (Japan Electronics and Information Technology
constraint ratio can be set to any value by MPa on pressure sensors and pipe materials. To Industries Association).
synchronizing the temperature waveform with raise the number of test cycles, the internal
the strain control waveform (triangular, generator is designed in a non-sealed structure,
trapezoidal, or program wave). As a result, this and the gap between the pressure intensifier and
testing machine is ideal for thermal fatigue special surface treated plunger is controlled to
testing of engine-related tubing materials, several µm. (Also available are testing machines
including mufflers, exhaust manifolds, and that support a maximum pressure of 300 MPa.) Environmental Resistance Evaluation of Electronic Instrumentation Components
exhaust pipes. It is compatible with the Fatigue
and Endurance Testing Machine EHF-E Series. WET-SPM Series Environment Controlled Scanning Probe Microscopes
This series of microscopes can observe changes in the surface shape of specimens at a high magnification of
several tens of thousands while controlling temperature and humidity. This makes it ideal for analyzing electronic
instrumentation parts and various other parts for automobiles under various environmental conditions.

Dynamic Properties Evaluation of Rubber Vibration Isolators Fatigue/Endurance Testing of Compact Electronic Components Evaluation of Voids in Solder

Rubber Vibration Isolator Dynamic Characteristics MMT Series Electromagnetic Force Micro Material inspeXio SMX-225CT Series Microfocus X-Ray CT System
Testing Machine Testing Machines Quality can be controlled by inspecting the electronic printed circuit boards used inside automobiles or in the
This testing machine can calculate This series of testing machines adopts an harsh environment of the engine compartment. In particular, discovery of the amount of solder under mounted
the properties of viscoelastic electromagnetic servo actuator to enable components and air bubbles in the solder can help minimize defects such as cracking due to heat and vibration.
materials from a static state to fatigue testing of compact parts in the
high cycles (max. 300 Hz). It can micro test force range. 10 N, 100 N, and
simply measure spring constant, 250 N models are available.
damping coefficient, and loss
coefficient. It also accommodates
testing under
temperature-controlled
environments in thermostatic Air
Bubbles
chambers.
Fluoroscopic Image of Solder CT Image of Solder on Printed CT Image of Solder Deficiency inspeXio SMX-225CT FPD HR Plus
Sections Circuit Board and Air Bubbles in Solder

Suspension and Other Power Engines, Motors, and Lithium-Ion Rechargeable Electronic Instrumentation
Bodies and Interiors
Transmission Systems Power Sources Batteries and Fuel Cells Components
14 This page may contain references to products that are not available in your country. Please contact us to check the availability of these products in your country. 15
