Data Processor                                                                                                 TGA-50 Series


       ˙ TA-60WS Thermal Analysis Workstation
         The workstation can be connected to up to four thermal analyzers to help smoothly perform routine work
         including measurement, analysis, and report output with easy operation. (Multi-channel and multi-task functions)
         The workstation is equipped with the OLE function and ASCII conversion function so that it can be linked with a
         wide variety of commercially-available software programs.
         t  Compatible with Windows 7.
                                                                                                           TA-60WS

        Options


       ˙ BLW-50 Cooling Blower
         The blower cools the heating furnace in a short time after measurement. It automatically operates after
         measurement is finished and automatically stops after the heating furnace is cooled.

       ˙ FC-60A Atmosphere Control Unit
                                                                                          BLW-50
         The TGA-50 Series has a single built-in gas flowmeter. Other than that, the flowrate of atmosphere gas in two flow
         lines can be regulated. It can be used for applications where atmosphere gas is switched by a built-in solenoid
         valve, linked with a temperature program.
         t  A remote cable (for the 50 Series, P/N: 346-68466-92) is necessary.
                                                                                                     FC-60A

        Sample Cells


           P/N            Description         P/N               Description
                                                                                               ᶅ
       ᶃ 201-52943  Crimp Cell, A1 dia. 6 × 1.5 (50 pcs.)  ᶊ 201-57268-90  Macro Cell, A1 dia. 6 × 5 (50 pcs.)
       ᶄ 201-51976  Platinum Cell, dia. 6 × 2.5  ᶋ 201-53843  Platinum Macro Cell, dia. 6 × 5  ᶃ  ᶄ  ᶆ  ᶇ  ᶈ  ᶉ
       ᶅ 201-56927  Platinum Cell Cap, dia. 6  ᶌ 201-56782-90  Quartz Macro Cell (crucible), dia.11 × 13.5
       ᶆ 201-54321  Alumina Cell, dia. 6 × 2.5  ᶍ 201-56825-90  Alumina Macro Cell (crucible), dia.10 × 14
                                                                                               ᶌ   ᶍ     ᶎ
       ᶇ 201-53102-84  Nickel Cell, dia. 6 × 2 (50 pcs.)  ᶎ 201-59795-91  Film Water Vapor Transmission Rate Measurement Cell (for the TGA-51)
       ᶈ 201-58294-90  Copper Cell, dia. 6 × 1.5 (50 pcs.)  Other cell                ᶊ   ᶋ
       ᶉ 201-54439  Quartz Cell, dia. 6 × 2.5  201-56569-01  Platinum Mesh Cell, dia. 11 × 12
