250mL~1,000mL (1L) Fixed angle rotor for large capacity

A-2506 Lightweight rotor A-5004 Lightweight rotor A-5006 Lightweight rotor A-1K4 Lightweight rotor
6 x 250mL 10.1kg 4 x 500mL 13.3kg 6 x 500mL 14.9kg 4 x 1,000mL 14.1kg
■ The rotor is approximately ■ The rotor is approximately ■ The rotor is approximately ■ The rotor is approximately
27% lighter and acceleration/ 40% lighter and acceleration/ 30% lighter and acceleration/ 26% lighter and it is easy to
deceleration are faster deceleration are faster deceleration are faster remove and handle.
(compared with AG-2506 rotor). (compared with AG-5004 rotor). (compared with AG-5006A rotor). Acceleration and deceleration
are faster (compared with AG-1K4
rotor).
■ The standard bottle with
sealing caps can be fully filled
with 1,000mL of samples.
■ The widemouth shaped
makes it easy to collect
samples.
By utilizing the click mechanism for A-type fixed angle rotors, it is easy to handle
on the level of tightening of the rotor lid.
7000 6000
Tube size (mm)
Rotor Name Nominal Capacity Maximum Speed Maximum RCF Maximum Speed Maximum RCF
diam. x length
rpm x g rpm x g
A-2506 ＊1,2 6 x 250 mL 60〜62.4 x 119〜137 13,000 26,830 11,500 21,000
A-5004 ＊1,2 4 x 500 mL 68〜70.2 x 155〜170.5 12,000 23,830 8,500 11,950
A-5006 ＊1,2 6 x 500 mL 68〜70.2 x 155〜170.5 10,000 18,890 8,000 12,090
A-1K4 ＊1,3,4 4 x 1,000 mL 95.7〜98.3 x 194.3〜196.8 9,000 15,760 ― ―

Biohazard-proof Sealing Adaptors

Sealing Adaptor for
High Speed Fixed Angle
Rotors

for 10mL Oak Ridge
High speed rotor type tubes
A-506, A-508 Code No.055-4280

7000 6000
Nominal Tube size (mm)
Rotor Name Tube type Code No.
Capacity diam. x length Maximum Speed Maximum RCF Maximum Speed Maximum RCF
rpm x g rpm x g
FEP 3114-0010
A-506 16.0〜16.3 22,000 49,240 20,000 40,700
10 mL PSF 3115-0010 ＊4
Oak ridge PC 3118-0010 x 055-4280
A-508 79〜92 20,000 45,610 17,000 32,960
PPCO 3119-0010
Rotor has prescribed operating life cycle, after that the rotor must be replaced.
For more details, please contact us.
＊1 A variety of tube adaptors are available on this rotor. For more details, please contact us.
＊2 Please refer to the rotor instruction manual for sample temperature.
＊3 Sample temperature with this rotor is maintained at 4℃ (when ambient temperature is 25℃).
＊4 This adapter is made of polyacetal and cap is polycarbonate.
