Page 6 - Kubota - 3700

The temperature of sample is kept 4℃ at maximum speed of rotation for all rotors (when the ambient temperature is 25℃).
Fixed angle rotor (5mL)

3740/3700
Tube sizes (mm) Adaptor
Rotor Name Nominal Capacity
diam. x length Maximum Speed Maximum RCF Code No.
rpm xg
AF-512 12 x 5mL 15 x 59 ＊1 15,000 20,880 ―

Autoclavable*
AF-512
12 x 5mL
Highly recommended when
the capacity of 2mL tube is
not enough.

Fixed angle rotor (middle size)

3740/3700
Tube sizes (mm) Adaptor
Rotor Name Nominal Capacity Maximum Speed Maximum RCF
diam. x length Code No.
rpm xg
AF-1408A 8 x 14mL 17 x 75〜100 ＊2 12,000 14,330 ―

Autoclavable*
AF-1408A
8 x 14mL
Falcon round bottom tubes
(dual-position snap cap) are
available.

3740/3700
Tube sizes (mm) Adaptor
Rotor Name Nominal Capacity
diam. x length Maximum Speed Maximum RCF Code No.
rpm xg
4 x 50mL 28.5〜29.0 x 102〜115 ＊3 15,000 21,880 ―
AF-5004RA 4 x 12mL 15.8〜16.4 x 103〜110 ＊4 15,000 20,630 055-7410
4 x 10mL 16.0〜16.3 x 79〜92 ＊5 15,000 20,630 055-4280 ＊6

Autoclavable*
AF-5004RA
4 x 50mL
10mL anti-biohazard sealing
adaptors (code no. 055-
4280) can be used.

3740/3700
Tube sizes (mm) Adaptor
Rotor Name Nominal Capacity Maximum Speed Maximum RCF
diam. x length Code No.
rpm xg
6 x 38mL 25.0〜25.6 x 87〜103 ＊7 15,000 21,880 ―
AF-3806A 6 x 30mL 25.4〜25.7 x 87〜102.6 ＊8 15,000 21,880 ―
6 x 10mL 16.0〜16.6 x 72〜82 ＊9 15,000 19,370 055-4570
Autoclavable*
AF-3806A
6 x 38mL
Rotor has prescribed operating life cycle, after that the rotor must be replaced.
For more details, please contact us.
＊ The number of times allowed for autoclaving is limited. For more details, please contact us.
＊1 Biobic 5mL sampling tubes and Watson 5mL mega tubes can be used.
＊2 Falcon round bottom tubes (catalogue no.352006, 352018, 352059) are available.
＊3 Nalgene tubes (catalogue no.3110-0500/PPCO, 3110-9500/PPCO, 3117-9500/PC, 3114-0050/FEP, 3115-0050/PSF, 3118-0050/PC,
3119-0050/PPCO, 3137-0050/PSF, 3138-0050/PC, 3139-0050/PPCO) and stainless steal tubes (code no.052-6910) can be used.
＊4 Nalgene tubes (catalogue no.3110-0120/PPCO, 3117-0120/PC) are available.
＊5 Nalgene tubes (catalogue no.3114-0010/FEP, 3115-0010/PSF, 3118-0010/PC, 3119-0010/PPCO) are available.
＊6 055-4280 sealing adaptors can be used for anti-biohazard.
＊7 Nalgene tubes (catalogue no.3110-0380/PPCO, 3117-0380/PC) are available.
＊8 Nalgene tubes (catalogue no.3114-0030/FEP, 3115-0030/PSF, 3118-0030/PC, 3119-0030/PPCO, 3138-0030/PC, 3139-0030/
PPCO) can be used.
＊9 Nalgene tubes (catalogue no.3118-0010/PC, 3114-0010/FEP, 3115-0010/PSF, 3119-0010/PPCO) can be used.
