Page 4 - Kubota - 3700
P. 4

The temperature of sample is kept 4℃ at maximum speed of rotation for all rotors (when the ambient temperature is 25℃).
            Bioshield rotor
          AF-2730 and AF-5004CS rotors are certified as biohazard-proof with the CAMR standards.
          Samples will not leak out from the rotor even if tubes break.
          These rotors can be used for inspections of BSE, SARS and so on.


                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                             30 x 1.5/2mL  9.5〜11.0 x 36〜42               20,820        ―
                                             14 x 0.5mL    7.0〜7.9 x 25〜34   14,000       17,530        ―
                                 AF-2730    14 x 0.2mL PCR  *1  5.9〜6.3 x 20〜24           16,430        ―
                                             30 x 0.5mL    7.0〜7.9 x 25〜34   14,000       18,850      055-7590
                                            30 x 0.2mL PCR  *2  5.9〜6.3 x 20〜24  14,000   16,870      055-0500
                     Autoclavable*
          AF-2730
          30 x 1.5/2mL
          4 types of tubes (1.5/2mL,
          0.5mL, 0.2mL PCR) can be
          used without adaptors.

                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                          4 x 50mL Conical tube  30 x 117  *3  12,000     14,970        ―
                                                                                                      055-1250  *3
                                          4 x 15mL Conical tube  17 x 121    12,000       14,490
                                                                                                      055-1280  *3
                                              4 x 14mL     15.6〜16.6 x 96  *4  12,000     13,850      055-0550
                                AF-5004CS     4 x 12mL    15.7〜16.4 x 102〜105  *5  12,000  14,330     055-1120
                     Autoclavable*        4 x Millipore Amicon  29.7 x 121    6,930        4,990        ―
                                              Ultra-15
          AF-5004CS                          4 x Sartorius
          4 x 50mL conical tube              Vivaspin 20     30 x 117         7,590        6,000        ―
          Various tubes can be used
          with adaptors.
            Fixed angle rotor for conical tubes

                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                          4 x 50mL Conical tube  30 x 117  *3  15,000     22,140        ―
                                          4 x 50mL Round Bottom tube  26.4〜28.7 x 98〜115  *6  15,000  20,880  055-1110
                                                                             15,000       21,130      055-1250
                                          4 x 15mL Conical tube  17 x 121
                                                                             12,000       13,520      055-1280
                                              4 x 14mL     15.6〜16.6 x 96  *4  15,000     20,120      055-0550
                     Autoclavable*            4 x 12mL    15.7〜16.4 x 102〜105  *5  15,000  20,880     055-1120
          AF-5004CH             AF-5004CH  4 x Millipore Amicon  29.7 x 121   7,130        5,000        ―
          4 x 50mL conical tube               Ultra-15
                                             4 x Sartorius
          15,000rpm/RCF 22,140xg             Vivaspin 20     30 x 117         7,810        6,000        ―
          Cap support structure which     4 x Millipore Amicon                                        055-1250
          prevents 50mL conical tubes         Ultra-4        17.3 x 124       8,930        7,490      055-1280
          from breaking is applied
          (patented).                        4 x Sartorius  17 x 122〜126      9,230        8,000      055-1250
                                             Vivaspin 2/6                                             055-1280
                                                                                  3740/3700
                                                            Tube sizes (mm)                            Adaptor
                                 Rotor Name  Nominal Capacity              Maximum Speed  Maximum RCF
                                                             diam. x length                            Code No.
                                                                              rpm           xg
                                          4 x 50mL Conical tube  30 x 117  *3  12,000     14,170        ―
                                                                                                      055-1250
                                          4 x 15mL Conical tube  17 x 121    12,000       13,520
                                                                                                      055-1280
                                              4 x 14mL     15.6〜16.6 x 96  *4  12,000     12,880      055-0550
                                              4 x 12mL    15.7〜16.4 x 102〜105  *5  12,000  13,360     055-1120
                     Autoclavable*        4 x Millipore Amicon
                                AF-5004CA     Ultra-15       29.7 x 121       7,130        5,000        ―
          AF-5004CA                          4 x Sartorius
          4 x 50mL conical tube              Vivaspin 20     30 x 117         7,810        6,000        ―
          50mL concal tube  with          4 x Millipore Amicon  17.3 x 124    8,930        7,490      055-1250
          large cap is available.             Ultra-4                                                 055-1280
                                             4 x Sartorius  17 x 122〜126      9,230        8,000      055-1250
                                             Vivaspin 2/6                                             055-1280
                                  Rotor has prescribed operating life cycle, after that the rotor must be replaced.
                                  For more details, please contact us.
                               * The number of times allowed for autoclaving is limited. For more details, please contact us.
                               *1  14 x 0.2mL PCR and 14 x 0.5mL tubes can be used together with outside 30 tube holes.
                               *2  0.2mL PCR tubes may not be used at maximum speed since they may not be resistant enough.
                               *3  The following 50mL conical tubes can be used: the diameter of the cap is within 36mm and the brands of the tubes are
                                  I  waki, Greiner, Corning, Sarstedt, Sumiron, Vioramo, BD Falcon, Fisher, Labcon, Nunc etc.
                               *4  Falcon tubes (catalogue no.352059) are available.
                               *5  Nalgene tubes (catalogue no.3110-0120/PPCO, 3117-0120/PC) can be used.
                               *6  Nalgene tubes (catalogue no.3110-0500/PPCO, 3110-9500/PPCO, 3117-9500/PC) and stainless steel tubes (code no.052-6910)
                                  can be used.
