Specifications
Model 3300
Maximum Speed¡ 15,000 rpm
Maximum RCF¡ 20,630 xg
Maximum capacity¡ 48 mL
Control system¡ Microprocessor control (brushless motor)
Speed, RCF(g), Time, 3 memory banks
Alarm display¡ Lid open, Imbalance, Over speed, Detected electrical abnormality in motor, inverter, lid interlock and speed sensor
Speed setting and indication¡ Digital display, in 100 rpm steps
RCF setting and indication¡ Digital display, in 100 xg steps
Timer setting and indication¡ Digital display, with HOLD function (continuous operation) and flashing
1 second to 99 seconds, 1 sec increments
1 minute to 99 minutes, 1 min increments
Sounds for informing end of centrifugation¡ 5 types and no sounding
Power requirements¡ Single phase 50/60Hz, 110V±10%, 115V±10%
Single phase 50/60Hz, 220V±10%, 230V±10%
Rated voltage and rated current¡ 110V 50/60Hz 3.0A, 115V 50/60Hz 2.9A, 220V 50/60Hz 1.5A, 230V 50/60Hz 1.4A
Power consumption and heat output¡ 110/115V 210W, 760kJ/h, 220/230V 200W, 720kJ/h
Size, weight¡ 32(W) x 39(D) x 27(H) cm · 20 kg, height with opened lid 58 cm ✳1
Conforming standard¡ IEC 61010-2-020
CE Marking (220V/230V)
(✳1) Not including projections.
All specifications and external appearance are subjects to be changed without notice.
* Use only rotors, adaptors and tube racks made by KUBOTA. Do not attempt to use rotors, adaptors or tube racks made by other manufacturers.
* Follow all instructions in the relevant Instruction & Service Manual when operating centrifuges.

RA-2024 RA-2724
Rotor lid is equipped with rotor. Rotor lid is equipped with rotor.

Autoclavable at 134˚C Autoclavable at 134˚C
Table of rotors and adaptors for Model 3300
Adaptor
Rotor Name Nominal Capacity Tube size (mm) Maximum Speed Maximum RCF Code No.
diam. x length
rpm
×g
24╳1.5/2mL 9.5〜11╳36〜42 15,000 20,630 —
RA-2024 24╳0.5mL 7〜7.9╳25〜34 15,000 18,360 055-7590
24╳0.2mL PCR 5.9〜6.3╳20〜24 15,000 16,100 055-0500
24╳1.5/2mL 9.5〜11╳36〜42 15,000 20,630 —
RA-2724 12╳0.5mL 7〜7.9╳25〜34 15,000 16,850 —
＊1 12╳0.2mL PCR 5.9〜6.3╳20〜24 15,000 14,840 —
＊1 4 types of tubes (1.5/2mL, 0.5mL and 0.2mL PCR tubes) can be used without adaptors.

Kubota has acquired ISO 9001 and ISO 13485 certification.
Products in this catalogue are designed for use only by people who have the requisite technical knowledge, and must always be used
Precautions
with considerable care and only for their intended purpose. People who do not have adequate technical knowledge or training should
for use
only use the products under appropriate supervision by someone with expert knowledge, or else accidents are likely to occur.
Please immediately • The rotor or buckets appear to be damaged or corroded. If any of the cases listed at the left occurs,
stop using • When the replacement period (years of operation, operating lifetime) immediately turn off the power, disconnect
of a rotor has passed.
the power cable plug or connecting
the products in any • The equipment emits a burning smell or becomes abnormally hot. IMPORTANT terminals from the main power outlet, place
of the cases listed • You receive a weak electric shock when you touch the equipment with a “Do not use” sign on the unit, and contact
Prohibited your bare hands.
on the right. • When any other abnormality or indication of failure is noticed. the nearest branch of Kubota Corporation.
Safety To use the equipment safely, be sure to read Do not misplace the instruction manual.
Keep the instruction manual nearby so that you can refer
the instruction manual carefully before you start
Precautions
operations. to it whenever necessary.
• The term of supplying spare parts for repair is 7 years after discontinuation of production (except spare parts which we are unable to procure).
• This catalogue is not for distribution in the USA, Canada and Mexico as products shown are not for sale in these countries.
